It uses a cable connection method to conduct real - time communication with the CNC machine tool, for transmission, automatic correction, automatic centering, and automatic compensation. The micro - vibration self - reset technology provides higher stability.

Type CNC Touch Probe

Specification Cable Touch Probe

Brand Qidu Metrology

Model DLP25

0757-22897623

Reservation Now

Detail

Main features

IP68 top - level protection rating, double - rubber ring protection structure

Modular assembly, arbitrary configuration of probe length

Extremely high operational stability, first - class in the industry

Indicator light design, the operating status is visually visible

Suitable for the high - gloss and grinder processing industries

Product advantages
Adopt cable connection mode to continue real - time communication with CNC machine tools.
Transmission, automatic correction, automatic centering, automatic compensation.
Micro - vibration self - reset technology, higher stability

Size display

20240703

Product Parameters

model number	DLP25
Repeatability of the probe in all directions Standard 50mm probe at 60MM/Min speed	<1um
Stylus trigger direction	±X,±Y,+Z
Stylus trigger force (50mm probe as standard)	XY plane 0.4~0.8N	Z direction 4.0N
Trigger protection stroke	XY plane +/-12.5°	Z direction 6.35mm
Signal Transmission Method	cord(computer)
Trigger life	>10 million times
Probe weight	80g
cord(computer)	5M Oil-resistant 4-core φ6mm
protection class	IP68
loperating temperature	0-60℃
